Steel grades

The chemistry of every grade we forge to specification. Search for the grade on your drawing; if it is not listed, send us the specification.

29
Grades: 5
Families: Certified per heat
Chemistry

Search a grade

Composition in per cent by weight. A blank cell indicates a figure we have not published.
Grade	Family	%C	%Mn	%S	%P	%Si	%Cr	%Ni	%Mo	Enquire
CL-2	Carbon steel	0.15–0.25	0.60–0.90	≤ 0.050	≤ 0.050	0.15–0.35	—	—	—	Use this grade
CL-3	Carbon steel	0.25–0.35	0.60–0.90	≤ 0.050	≤ 0.050	0.15–0.35	—	—	—	Use this grade
CL-4	Carbon steel	0.40–0.50	0.60–0.90	≤ 0.050	≤ 0.050	0.15–0.35	—	—	—	Use this grade
C-25	Carbon steel	0.25–0.35	0.60–0.90	≤ 0.050	≤ 0.050	0.05–0.35	—	—	—	Use this grade
C-35	Carbon steel	0.30–0.40	0.60–0.90	≤ 0.050	≤ 0.050	0.05–0.35	—	—	—	Use this grade
C-40	Carbon steel	0.35–0.45	0.60–0.90	≤ 0.050	≤ 0.050	0.05–0.35	—	—	—	Use this grade
C-45	Carbon steel	0.40–0.50	0.60–0.90	≤ 0.050	≤ 0.050	0.05–0.35	—	—	—	Use this grade
C-60	Carbon steel	0.57–0.65	0.50–0.80	≤ 0.045	≤ 0.045	0.15–0.35	—	—	—	Use this grade
45C8	Carbon steel	0.40–0.50	0.60–0.90	≤ 0.050	≤ 0.050	0.15–0.35	—	—	—	Use this grade
35C8	Carbon steel	0.30–0.40	0.60–0.90	≤ 0.050	≤ 0.050	0.15–0.35	—	—	—	Use this grade
CK-35	Carbon steel	0.32–0.39	0.50–0.80	≤ 0.035	≤ 0.035	≤ 0.40	—	—	—	Use this grade
CK-45	Carbon steel	0.42–0.50	0.50–0.80	≤ 0.035	≤ 0.035	0.15–0.35	—	—	—	Use this grade
EN-8	Carbon steel	0.35–0.45	0.50–0.80	≤ 0.060	≤ 0.060	0.05–0.35	—	—	—	Use this grade
EN-9	Carbon steel	0.50–0.60	0.50–0.80	≤ 0.060	≤ 0.060	0.05–0.35	—	—	—	Use this grade
AISI-1015	Carbon steel	0.13–0.19	0.30–0.60	≤ 0.050	≤ 0.040	≤ 0.10	—	—	—	Use this grade
AISI-1045	Carbon steel	0.43–0.50	0.60–0.90	≤ 0.050	≤ 0.040	0.10–0.20	—	—	—	Use this grade
EN-18	Alloy steel	0.35–0.45	0.60–0.95	≤ 0.050	≤ 0.050	0.10–0.35	0.85–1.15	—	—	Use this grade
EN-41B	Alloy steel	0.35–0.45	≤ 0.65	≤ 0.050	≤ 0.050	0.10–0.35	1.40–1.80	≤ 0.40	0.10–0.25	Use this grade
10CrNiMo6	Case hardening	0.08–0.13	0.30–0.60	≤ 0.025	≤ 0.025	0.15–0.35	1.00–1.40	1.40–1.80	0.25–0.35	Use this grade
17CrNiMo6	Case hardening	0.14–0.19	0.30–0.60	≤ 0.025	≤ 0.025	0.10–0.40	1.40–1.70	1.40–1.70	0.25–0.35	Use this grade
EN-353	Case hardening	≤ 0.20	0.50–1.00	≤ 0.050	≤ 0.050	≤ 0.35	0.75–1.25	1.00–1.50	0.08–0.15	Use this grade
42CrMo4	Cr-Mo	0.38–0.45	0.50–0.80	≤ 0.030	≤ 0.035	≤ 0.40	0.90–1.20	—	0.15–0.70	Use this grade
EN-19	Cr-Mo	0.35–0.45	0.50–0.80	≤ 0.050	≤ 0.050	0.10–0.35	0.90–1.50	—	0.20–0.40	Use this grade
4130	Cr-Mo	0.28–0.33	0.40–0.60	≤ 0.025	≤ 0.025	0.15–0.35	0.80–1.10	—	0.15–0.25	Use this grade
4140	Cr-Mo	0.38–0.43	0.75–1.00	≤ 0.040	—	0.15–0.35	0.80–1.10	—	0.15–0.25	Use this grade
709M40	Cr-Mo	0.36–0.44	0.70–1.00	≤ 0.040	—	0.10–0.40	0.90–1.20	—	0.25–0.35	Use this grade
817M40	Ni-Cr-Mo	0.36–0.44	0.45–0.70	≤ 0.040	—	0.10–0.40	1.00–1.40	—	0.20–0.35	Use this grade
34CrNiMo6	Ni-Cr-Mo	0.30–0.38	0.50–0.80	≤ 0.035	≤ 0.035	≤ 0.40	1.30–1.70	1.30–1.70	0.15–0.30	Use this grade
EN-24	Ni-Cr-Mo	0.36–0.44	0.60–0.90	≤ 0.050	≤ 0.050	0.10–0.35	1.35–1.65	—	—	Use this grade

Figures are the specification ranges for each grade. The chemistry supplied with your part is that of its own heat, as recorded on the test certificate.

Working to a grade not listed here?

Send us the specification and we will confirm whether we can forge it.

Send the specification
